China TFT Color Display, Higher Resolution, Sharper Colors Launch Tech Crp123 Car Diagnostic Machine

Product Description

Featuring the unique and 3.5 inch TFT color display, the CRP 123 OBDII/EOBD code reader supports all 10 modes of OBDII test for a complete diagnosis. It is truly the ultimate in power and affordability , allowing users to do their jobs faster. Graph, Record, Replay data and troubleshooter code tips help users to save diagnosis and repair time.

The CRP123,the most advanced and multifunctional code reader powered by its exclusive technology, are designed for technicians to troubleshoot four systems for most of the major vehicle on the road today. Featuring the unique multifunctional keys and 3.5?? TFT color display. Launch?s new CRP123 offers the same features and functions as the CRP122, but come with the added benefits of read DataStream for 4 systems and vehicle diagnostic report.

Launch X431 Creader CRP123 Features

1.3.5 TFT color display, Higher resolution, sharper colors

2.Works on ALL 1996 and newer vehicles (OBDII& CAN)

3.Retrieves generic (P0, P2,P3 and U0), manufacturer specific (P1, P3 and U1) codes, and pending codes

4.Easily determindes the cause of Check Engine Light

5.Turns off MIL, clears codes and resets monitors

6.Displays DTS definitions on the 320*480 TFT corlor screen

7.Views freeze frame data

8.Displays monitor and I/M rediness status

9.Reads live PCM data stream

10.Displays live O2 sensor test data

11.Performs modules present test

12.Enhanced OBD II Mode 6

13.Graphs Display, Data Record& Replay and DTCs tips guide users to the root cause of trouble code faster, 14.saving diagnosing and repari time

15.Retrieves vehicle information (VIN, CIN and CVN )

16.Support large extension memory card

17.Multilingual menus, DTC definitions- English, Chinese, etc

18.Extremely easy to use and highly reliable

19.Internet upgradeable

20.Prints data via PC

Launch Creader VII+ Specification:

Screen:3.5 inch, 320*480 TFT LCD true color display
Input voltage:9-18V
Connection:standard 16 PIN OBD diagnostic interface
Working temperature:0-50°C
Storage ambient temperature:-20 to 70°C
Dimension:136*73*22(mm)
Weight:<350g

The newest Function Improvement:
For FIAT Diagnostic Software for CRP Series V11.31
For FORD Diagnostic Software for CRP Series V11.40
For NISSAN Diagnostic Software for CRP Series V10.20
For KIA Diagnostic Software for CRP Series V10.40
For Kia Diagnostic Software for X-431 Series V10.30
For SUBARU Diagnostic Software for X-431 Series V10.07
For USAFORD Diagnosis software V11.20 for CRP
For CRP123 USAFORD Diagnostic Software

CRP123 Parameter:

Screen	3.5 inch, 320*480 TFT LCD true color display
Input voltage	9-18V
Connection	standard 16 PIN OBD diagnostic interface
Working temperature	0-50°C
Storage ambient temperature	-20 to 70°C
Dimension	1367322(mm)
Weight	<350g

Features Difference between CRP 123 ,CRP 129 and CRP 229

Features	Creader VII+	Creader VIII	CRP123	CRP129	CRP 229
OBD II		Y	Y	Y	Y
Support OBD					Y
DTC help		Y		Y	Y
Waveform Diagnosis		Y		Y	Y
Diagnostic Software	29 cars / 4 system	40 cars / 4 system	32 cars / 4 system	43 cars / 4 system	43 cars / system-wide
Support Functions	Read code, clear code and data stream		Read code, clear code and data stream	Read code, clear code, data flow, ID information	Read code, clear code, data flow, ID information
Reset function		Brake / Oil / SAS		Brake / Oil / SAS / Battery	Brake / Oil / SAS / Batter
Recording and playback			Y	Y	Y
Multi-language			Britain Faxi De Italy and Russia	Britain Faxi De Italy and Russia	Britain Faxi De Italy and Russia
Online upgrade			Y	Y	Y
Diagnostic socket location reminders				Y	Y
Remote Diagnosis					Y
Golo Function					Y
Data Query					Y
Multimedia					Y
Enquiry					Y
